Simulator enclosure: what you get
An enclosure holds the impact screen and side netting in one frame and catches mishits. Its frame size fixes the minimum room width and height, and the screen shape decides which projector setup fills it cleanly.
Sizes offered
| Size or configuration | Area | Shape |
|---|---|---|
| Vanish 9 - (89" x 89" projectable area) | — | — |
| Vanish 11 - (120” x 90” projectable area) | — | — |
| Vanish 13H - (144” x 108” projectable area) | — | — |
| Vanish 16 - (183" x 90" projectable area) | — | — |
| Vanish 16H - (183” x 102” projectable area) | — | — |
FOREference calculationShape = width ÷ height, matched to the nearest standard aspect ratio. A 16:9 projector on a 4:3 screen uses 75% of its frame; the throw calculator shows the distance for your screen.
Listed details
| Item | Seller figure |
|---|---|
| Vanish 9 | 89"W x 89"H projectable area |
| Vanish 11 | 120"W x 90"H projectable area — 4:3 ratio |
| Vanish 13 | 144"W x 108"H projectable area |
| Vanish 16 | 183"W x 102"H projectable area — 16:9 ratio |
| Enclosure Type | Retractable roll-up — hand crank or powered motor (select at checkout) |
| Impact Screen Material | 3-ply premium construction-grade impact screen |
| Side Screens | 2 side screens, 5ft depth |
| Enclosure System | Independent baffle system — front baffle, 2 side baffles, ceiling panel, 2 corner pieces |
| Mounting System | Universal brackets — wall or ceiling mount |
| Ceiling Height Compatibility | 108" – 144" |
| Clearance Required — Back | 8" – 12" from back wall or surface |
| Clearance Required — Sides | 6" – 8" from side walls |
| Motor Power (powered models) | 120V ~ 60Hz, 280W / 2.4A — standard 110V outlet |
| Max Motor Run Time | 4 minutes continuous (thermal shutoff protection built in) |
Features the seller lists
- Vanish 11 Dimensions
- Vanish 16 Dimensions
- 30-Day Returns
- Manufacturer Warranty Honored
Other options and materials
- Retractable Application: Hand Crank, Power/Automatic
Planning notes
Plan the room around the frame, then check the projector distance for the screen shape.
| Check | Rule of thumb |
|---|---|
| Width | Frame width + about 6 in each side |
| Height | Frame height + space to assemble; the ceiling must also clear your swing |
| Depth | Screen gap (8–12 in) + 8–10 ft to the ball + about 4.5 ft behind it |
| Projector | Short-throw lenses mount about 5–8 ft from a 10–12 ft wide 4:3 screen |
Use the room size calculator with your launch monitor to confirm depth.
Fit check
Checks to make against your room and equipment before ordering.
✓ Required? Check firsti Good to know
- ✓SizeOptions: Vanish 9 - (89" x 89" projectable area), Vanish 11 - (120” x 90” projectable area), Vanish 13H - (144” x 108” projectable area), Vanish 16 - (183" x 90" projectable area), Vanish 16H - (183” x 102” projectable area)
- ?Room fitMeasure the floor area and ceiling before ordering; allow space to assemble.
- iDeliveryLarger items may ship by freight or in several boxes; confirm lead time and returns with the seller.
Specifications
Each figure is labelled with where it comes from. Numbered references link to the source list below.
Manufacturer storeRetailer listingFOREference calculationNot verified
Published specifications
| Vanish 9 | 89"W x 89"H projectable area[S1] | Retailer listing |
|---|---|---|
| Vanish 11 | 120"W x 90"H projectable area — 4:3 ratio[S1] | Retailer listing |
| Vanish 13 | 144"W x 108"H projectable area[S1] | Retailer listing |
| Vanish 16 | 183"W x 102"H projectable area — 16:9 ratio[S1] | Retailer listing |
| Enclosure Type | Retractable roll-up — hand crank or powered motor (select at checkout)[S1] | Retailer listing |
| Impact Screen Material | 3-ply premium construction-grade impact screen[S1] | Retailer listing |
| Side Screens | 2 side screens, 5ft depth[S1] | Retailer listing |
| Enclosure System | Independent baffle system — front baffle, 2 side baffles, ceiling panel, 2 corner pieces[S1] | Retailer listing |
| Mounting System | Universal brackets — wall or ceiling mount[S1] | Retailer listing |
| Ceiling Height Compatibility | 108" – 144"[S1] | Retailer listing |
| Clearance Required — Back | 8" – 12" from back wall or surface[S1] | Retailer listing |
| Clearance Required — Sides | 6" – 8" from side walls[S1] | Retailer listing |
| Motor Power (powered models) | 120V ~ 60Hz, 280W / 2.4A — standard 110V outlet[S1] | Retailer listing |
| Max Motor Run Time | 4 minutes continuous (thermal shutoff protection built in)[S1] | Retailer listing |
| Handedness | Right and left-handed golfers — all models[S1] | Retailer listing |
| Installation | 2-person job, approximately 1 hour. Power tools not required.[S1] | Retailer listing |
| Warranty | 2 years — defects in materials and workmanship[S1] | Retailer listing |
| Front Screen Width (bracket to bracket) | 128.5"[S1] | Retailer listing |
| Sizes offered | Vanish 9 - (89" x 89" projectable area), Vanish 11 - (120” x 90” projectable area), Vanish 13H - (144” x 108” projectable area), Vanish 16 - (183" x 90" projectable area), Vanish 16H - (183” x 102” projectable area)[S2] | Manufacturer store |
Limitations to weigh
- Specifications are the seller's; FOREference has not measured this product.
Alternatives worth comparing
Where to buy
3 specialist sellers list this exact product. Prices were observed on 30 Sep 2026; confirm the current price, stock and included items before ordering.
| Seller | Listed price | Type |
|---|---|---|
| SportScreen | $2,999.99–$5,899.99 | Manufacturer store |
| Rain or Shine Golf | $2,999–$5,499 | Specialist retailer |
| Golf Bays | $2,999–$3,999 | Specialist retailer |
$2,999.99SportScreen listed price (configurations to $5,900) · seen 30 Sep 2026
Every link opens the product page for this exact model. We may earn a commission; it never changes what we publish. Disclosure
Questions buyers ask
What sizes does the SportScreen Vanish Series Retractable Golf Enclosure come in?
Vanish 9 - (89" x 89" projectable area), Vanish 11 - (120” x 90” projectable area), Vanish 13H - (144” x 108” projectable area), Vanish 16 - (183" x 90" projectable area), Vanish 16H - (183” x 102” projectable area)
Where can I buy the SportScreen Vanish Series Retractable Golf Enclosure?
3 specialist sellers list it: SportScreen, Rain or Shine Golf and Golf Bays.
Sources and verification
- Rain or Shine Golf — SportScreen Vanish Retractable — product page and specifications Retrieved 30 Sep 2026
- SportScreen — Vanish Series Retractable Golf Enclosure — product page Retrieved 30 Sep 2026
- Golf Bays — Vanish Series Retractable Golf Enclosure (Vanish 9) — product page Retrieved 30 Sep 2026
FOREference has not tested this product hands-on. This reference is compiled from the sources above; our calculations are labelled and show their working. Last verified 30 Sep 2026. How we work
