Impact screen: what you get
An impact screen stops the ball and shows the projected image. Screen size sets the projector distance, and the weave affects image sharpness, noise and bounce-back.
Sizes offered
| Size or configuration | Area | Shape |
|---|---|---|
| 8' x 10.5' | 84 sq ft | ≈ 4:3 |
| 9' x 12' | 108 sq ft | ≈ 4:3 |
| Single Layer (Increased Durability) | — | — |
| Triple-Layer Premium Screen (Quieter/Less Bounceback) | — | — |
FOREference calculationShape = width ÷ height, matched to the nearest standard aspect ratio. A 16:9 projector on a 4:3 screen uses 75% of its frame; the throw calculator shows the distance for your screen.
Listed details
| Item | Seller figure |
|---|---|
| Available Sizes | 8x10 (8'H x 10'5"W x 4'2"D) | 9x12 (9'H x 12'W x 4'2"D) |
| Overall Footprint | 11'W x 15'D x 8.1'H |
| Frame Material | 1.5" powder-coated extruded aluminum with steel bracket hardware |
| Frame Assembly | Push-button quick-connect — all tools included, under 20 minutes |
| Screen Material | Ballistics grade woven polyester |
| Screen Options | Single layer or triple layer |
| Ball Speed Rating | Up to 250 mph |
| Curtains | Blackout ripstop nylon material |
| Side Netting | 8'H x 10'L triangular configuration x2 | 1" velcro attachment |
| Frame Padding | Velcro-integrated frame padding flaps |
| Sandbags | Included (sand not included) |
| Bungees | 6" ball bungees included |
| Screen Warranty | 1-year limited warranty |
| Frame & Turf Warranty | 3-year warranty |
Features the seller lists
- 10-Minute Setup
- The Longest Warranty In The Game
- Longest Warranty In The Category
Planning notes
Plan the room around the frame, then check the projector distance for the screen shape.
| Check | Rule of thumb |
|---|---|
| Width | Frame width + about 6 in each side |
| Height | Frame height + space to assemble; the ceiling must also clear your swing |
| Depth | Screen gap (8–12 in) + 8–10 ft to the ball + about 4.5 ft behind it |
| Projector | Short-throw lenses mount about 5–8 ft from a 10–12 ft wide 4:3 screen |
Use the room size calculator with your launch monitor to confirm depth.
Fit check
Checks to make against your room and equipment before ordering.
✓ Required? Check firsti Good to know
- ✓SizeOptions: 8' x 10.5', 9' x 12', Single Layer (Increased Durability), Triple-Layer Premium Screen (Quieter/Less Bounceback)
- ?Room fitMeasure the floor area and ceiling before ordering; allow space to assemble.
- iDeliveryLarger items may ship by freight or in several boxes; confirm lead time and returns with the seller.
Specifications
Each figure is labelled with where it comes from. Numbered references link to the source list below.
Manufacturer storeRetailer listingFOREference calculationNot verified
Published specifications
| Available Sizes | 8x10 (8'H x 10'5"W x 4'2"D) | 9x12 (9'H x 12'W x 4'2"D)[S1] | Retailer listing |
|---|---|---|
| Overall Footprint | 11'W x 15'D x 8.1'H[S1] | Retailer listing |
| Frame Material | 1.5" powder-coated extruded aluminum with steel bracket hardware[S1] | Retailer listing |
| Frame Assembly | Push-button quick-connect — all tools included, under 20 minutes[S1] | Retailer listing |
| Screen Material | Ballistics grade woven polyester[S1] | Retailer listing |
| Screen Options | Single layer or triple layer[S1] | Retailer listing |
| Ball Speed Rating | Up to 250 mph[S1] | Retailer listing |
| Curtains | Blackout ripstop nylon material[S1] | Retailer listing |
| Side Netting | 8'H x 10'L triangular configuration x2 | 1" velcro attachment[S1] | Retailer listing |
| Frame Padding | Velcro-integrated frame padding flaps[S1] | Retailer listing |
| Sandbags | Included (sand not included)[S1] | Retailer listing |
| Bungees | 6" ball bungees included[S1] | Retailer listing |
| Screen Warranty | 1-year limited warranty[S1] | Retailer listing |
| Frame & Turf Warranty | 3-year warranty[S1] | Retailer listing |
| Included | Ballistics grade impact screen, powder-coated aluminum framing, all hardware and tools, nylon blackout curtain enclosure, triangular side netting x2, sandbags, velcro-integrated frame padding flaps, 6" ball bungees[S1] | Retailer listing |
| Sizes offered | 8' x 10.5', 9' x 12', Single Layer (Increased Durability), Triple-Layer Premium Screen (Quieter/Less Bounceback)[S1] | Retailer listing |
Limitations to weigh
- Specifications are the seller's; FOREference has not measured this product.
Alternatives worth comparing
Where to buy
Our link opens this exact product page. Prices and stock change; check before you order.
$1,999Rain or Shine Golf listed price (configurations to $3,499) · seen 30 Sep 2026
Every link opens the product page for this exact model. We may earn a commission; it never changes what we publish. Disclosure
Questions buyers ask
What sizes does the SwingBay Golf Simulator Screen & Enclosure come in?
8' x 10.5', 9' x 12', Single Layer (Increased Durability), Triple-Layer Premium Screen (Quieter/Less Bounceback)
Where can I buy the SwingBay Golf Simulator Screen & Enclosure?
1 specialist seller list it: Rain or Shine Golf.
Sources and verification
- Rain or Shine Golf — SwingBay Golf Simulator Screen & Enclosure — product page and specifications Retrieved 30 Sep 2026
FOREference has not tested this product hands-on. This reference is compiled from the sources above; our calculations are labelled and show their working. Last verified 30 Sep 2026. How we work
